Plumes on Enceladus: A Tidal Squeeze

An object in an elliptical, egg-shaped orbit experiences interesting gravitational stresses. Enough so that the changing forces it endures may be the cause of the plumes of water vapor that Cassini found on Saturn’s moon Enceladus in 2005. In essence, the tiny moon is being alternately squeezed and stretched as it makes its way around the planet. These tidal forces cause existing fault lines to rub against each other, producing enough heat to turn ice into water vapor and ice crystals.

The cracked surface of Enceladus

That’s the conclusion of new work by Francis Nimmo (University of California — Santa Cruz) and team, who note the warmer surface of Enceladus’ southern pole and the presence of the famous ‘tiger stripes,’ which appear to be tectonic fault lines. “We think the Tiger Stripes are the source of the plumes,” says Nimmo, “and we made predictions of where the Tiger Stripes should be hottest that can be tested by future measurements.”

Image: This is a mosaic of Enceladus compiled from 21 images taken by the Cassini spacecraft as it swooped past the moon’s south pole on July 14, 2005. The Tiger Stripe region appears as a series of long cracks toward the bottom. The mosaic is in false color, and includes images taken in various types of light, including ultraviolet and infrared. Credit: NASA/JPL/Space Science Institute.

The process at work is sublimation, which does not require water to go through a liquid state before becoming a vapor (as a guy who used to live in upstate New York, I’m reminded of the way snow can dissipate over time even when the temperature never gets above the freezing point — that’s sublimation). Interestingly enough, the study does suggest that Enceladus contains a liquid ocean deep beneath its ice, under a shell perhaps tens of kilometers thick. The theory almost demands an ocean to be there because otherwise tidal forces couldn’t generate enough movement in the faults to produce the needed heat.

A second paper in the same issue of Nature examines tidal forces and their effect on Enceladus, with this comment by lead author Terry Hurford (NASA GSFC), discussing his team’s computer model for calculating stress effects on the Tiger Stripes:

“We found that because of the way the Tiger Stripes are oriented on the surface, when Enceladus is farthest from Saturn, the stresses in the region pull most of them open, and when Enceladus is closest to Saturn, the stresses force most of them to close. Different stripes open at different times in the orbit. Assuming they erupt as soon as they open, exposing liquid water to the vacuum of space, we can predict which stripes will be erupting at certain times in the orbit. Also, because most of the stripes are open when Enceladus is farthest from Saturn, we expect the eruptive activity to be greatest at this time.”

The Nimmo paper is “Shear heating as the origin of the plumes and heat flux on Enceladus,” Nature 447 (17 May 2007), pp. 289-291; abstract here. The second paper is Hurford et al., “Eruptions arising from tidally controlled periodic openings of rifts on Enceladus,” in the same issue, pp. 292-294 (abstract) Future Cassini observations will be needed to get better imagery of the Tiger Stripes to differentiate the sources of the eruptions.

Comments on this entry are closed.

  • stargazerdude May 17, 2007, 22:59

    A cut and paste from a Spacedotcom story–“Using computer models, researchers led by Francis Nimmo of the University of California, Santa Cruz found that ice sheets grinding against each other at tiger stripe fractures generate enough heat to melt some of the ice. The melted ice would sublimate into water vapor and float directly into space.”

    Look at the Cassini photos. Do you see water vapor “…float directly into space”.

    I see geysers, with a LOT of motive force behind the water vapor; gigawatts worth, from some SERIOUS energy input into a body of water under the crust.

  • Todd May 18, 2007, 0:25

    “I see geysers, with a LOT of motive force behind the water vapor …”

    For a body as small as Enceladus, you don’t need much force to “float” water vapor and particles to escape velocity. The Cassini images don’t offer the perspective of real-time geyser-watching.

    I’m wondering about the history of a body like Hyperion. It has a certain orbital eccentricity. It orbits near Titan. Why is a moon so large so porous? Could it have vented its liquids earlier?

  • ljk August 15, 2007, 12:22

    Frigid enceladus: an unlikely harbor for life

    http://www.news.uiuc.edu/news/07/0814enceladus.html

    Contact:

    James E. Kloeppel, Physical Sciences Editor

    1-217-244-1073 kloeppel@uiuc.edu

    Released 8/14/07

    CHAMPAIGN, Ill. — A new model of Saturn’s icy moon Enceladus may quell hopes of finding life there. Developed by researchers at the University of Illinois, the model explains the most salient observations on Enceladus without requiring the presence of liquid water.

    Orbiting Saturn since June 30, 2004, the Cassini spacecraft has revealed a south polar region of Enceladus with an elaborate arrangement of fractures and ridges, intense heat radiation and geyser-like plumes consisting of ice crystals and gases such as methane, nitrogen and carbon dioxide. The plumes erupt from vents located in large fractures called “tiger stripes” that cut across the south pole.

    The plumes monitored by Cassini had a rate of discharge similar to Old Faithful geyser in Yellowstone National Park. Dubbed “Cold Faithful,” the first model that was proposed to explain the plumes suggested the plumes tap into shallow pockets of liquid water in a water-ice shell.

    Last year, U. of I. geology professor and planetary scientist Susan Kieffer and colleagues proposed an alternate model, which they called “Frigid Faithful.” In this model, the plumes originate in the dissociation of certain stiff compounds of ice, called clathrates, which may cover Enceladus to a depth of tens of kilometers. The researchers published their model in the Dec. 15, 2006, issue of the journal Science.

    “Frigid Faithful gives a straightforward account of the measured composition, including the gases left unaccounted by Cold Faithful,” said Kieffer, who holds a Charles R. Walgreen Jr. Chair at Illinois and is also a professor in the University’s Center for Advanced Study, one of the highest forms of campus recognition.

    “Perhaps more important, the plumes of Frigid Faithful could remain active far below the freezing point of water, under the frigid conditions that might be surmised inside a tiny, icy moon,” Kieffer said.

    Now, Kieffer, mechanical science and engineering professor Gustavo Gioia, geology research associate Pinaki Chakraborty and geology professor and department head Stephen Marshak have expanded the model to account for both the tectonic features and the heat transport in the southern hemisphere. They describe the model in a paper accepted for publication in the Proceedings of the National Academy of Sciences and posted on the journal’s Web site.

    By examining the deformation of a clathrate-rich shell containing a mildly warm heat source buried under the south pole, the researchers show it is possible for a frigid, stiff Enceladus without a shifting interior (such as plate tectonics on Earth) to develop fractures and ridges, and convey heat at the observed rate.

    “As the heat source warmed at depth, it expanded and stretched the clathrate-rich shell above, giving rise to tensile stresses in the south polar cap,” said Gioia, lead author of the paper. “As a result, the shell cracked, forming the four 130 kilometer-long fractures known as tiger stripes.”

    The researchers estimate the heat source could have been only 40 degrees warmer than the surrounding shell. “In this model, the tiger stripes are analogous to the cracks that form in the glazing of a porcelain vessel when the vessel is filled with hot tea,” Gioia said.

    The researchers also show that, northwards of the south polar cap (in which the stresses were tensile), the stresses turned first from tensile to compressive – forming the ring of ridges that circles the tiger stripes – and then back to tensile – forming the set of “starfish” fractures that radiates northward from the ring of ridges. Thus the model explains the formation of the entire arrangement of fractures and ridges observed by Cassini on the southern hemisphere of Enceladus.

    The Illinois researchers estimate the tiger stripes cut through the shell of Enceladus to a depth of about 35 kilometers. After the tiger stripes formed, the clathrates exposed on the cracked surfaces of the tiger stripes were decompressed. Upon decompression, the exposed clathrates absorbed heat from the source at depth and dissociated explosively, exposing more clathrates to decompression, in a process that continues today.

    The gaseous products of clathrate dissociation rush up the tiger stripes, transporting heat to the surface where they may occasionally leak in the form of plumes. The transport of heat by fast-moving gases is called “heat advection.” The cracked shell of Frigid Faithful acts as a gigantic “advection machine,” which efficiently conveys heat from the source to the surface.

    In contrast to “heat conduction”, where the transport of heat (in a bar of steel, for example) can only occur from points at higher temperature towards points at lower temperature, heat advection takes place at a nearly uniform temperature.

    The implication is that Frigid Faithful’s shell remains close to the surface temperature to a depth of about 35 kilometers, Gioia said. According to the Cassini measurements, the surface temperature might be as many as 150 degrees below the freezing point of water.

    “This is indeed a frigid Enceladus,” Gioia said. “It appears that high heat fluxes, geyser-like activity and complex tectonic features can occur even if moons do not have hot, liquid or shifting interiors.”

    While the Enceladus envisioned by the Illinois researchers is unlikely to possess liquid water and therefore unlikely to harbor life, it is compatible with the available evidence and is the only model that has been shown to explain the origin of the arrangement of fractures and ridges documented by Cassini.”

    The National Science Foundation funded the work.
