Perspectives on Pluto and Charon

We’re just past the 35th anniversary of the discovery of Pluto’s moon Charon. Or more precisely, we just passed the July 7 date when the announcement of that discovery, which had actually happened in June of 1978, was made. That turned my thoughts back to Larry Niven’s story “Wait It Out,” which tells the tale of two astronauts who are stranded on Pluto’s surface. Removing his helmet to die quickly, the narrator discovers that he lives on in a strange semi-stasis, his brain now a superconductor. First published in 1968 (in All the Myriad Ways), the story contains no Charon, but the scene lingers with me. I’ll quote just a patch of it, though I’ve quoted it before:

A superconductor is what I am. Sunlight raises the temperature too high, switching me off like a damned machine at every dawn. But at night my nervous system becomes a superconductor. Currents flow; thoughts flow; sensations flow. Sluggishly. The one hundred and fifty-three hours of Pluto’s rotation flash by in what feels like fifteen minutes. At that rate I can wait it out.

All of that, coupled with the Charon anniversary, had me thinking about what Pluto’s surface would look like with the moon included. A couple of things come to mind here. Pluto’s axial tilt (obliquity) is 124 degrees, which means that Pluto’s rotational axis is nearly in the plane of its orbit. Charon orbits the dwarf planet in its equatorial plane. Recall too that the length of Pluto’s day is the same as the orbital period of Charon. The result: Charon always presents the same face toward Pluto and vice versa.

That may seem similar to our own Moon, but because Charon orbits over Pluto’s equator, it does not appear to move relative to the horizon. This Southwest Research Institute page on the Phases of Charon, written by Marc Buie, gives further background, but the point is that because Charon orbits Pluto in the same way that communications satellites orbit the Earth, there is never a moonrise from Pluto’s surface. Moreover, the moon is invisible over half the planet.

We wind up with a moon that undergoes regular phases. If the Sun were directly over Pluto’s equator at the start of Plutonian spring, then Charon at its ‘new moon’ phase would move directly in front of the Sun, to produce an eclipse. As it moves through the rest of its 6.4 day orbit, it would progress through a series of phases. The diagram below tells the story:


Image: The Sun crossed the equator in 1988 during the middle of a 6 year season of eclipses that would have been spectacular to watch. This marked the start of spring in the northern hemisphere and the full moon was really full. Credit: SwRI/Marc W. Buie.

But take a look at the start of summer in the Northern hemisphere (this will next happen in 2030). Here the Sun passes over 56 degrees north latitude, roughly where Scotland is on Earth:


And as Buie goes on to explain:

Another longer term cycle also affects the phases and that is Pluto’s orbit around the sun. Since Pluto’s rotation axis is tipped on its side, it has very pronounced seasons. Unlike our Moon, Charon also undergoes the same exact seasons. The only time you’d see a completely full moon would be at the start of spring or fall. At the start of summer or winter, just over half the surface would be illuminated at its fullest, either the north or south polar regions depending on the season.

Charon orbits some 19,000 kilometers away from Pluto. From its surface, Pluto is gigantic in the sky, more than 14 times as wide and with 200 times the area of our Moon in the sky, as Alan Stern notes in his latest PI’s Perspective for the New Horizons mission. We can thank James Christy and Robert Harrington (U.S. Naval Observatory) for the discovery of the largest moon relative to its planet in the Solar System. And we can thank New Horizons for the image below, showing Pluto and Charon as seen from the spacecraft. New Horizons was 550 million miles from Pluto, further than the distance between the Earth and Jupiter, when the photo was taken on July 1, giving us a bit of a gut-check on the distances just to our own outer system.


Two years from now, New Horizons will pass just over 12,000 kilometers above Pluto’s surface, where the LORRI imager will be able to spot features about the size of a football field. This is going to be a fascinating system to untangle. Charon’s interior is thought to be a combination of rock and water ice at about 50/50 proportions, while Pluto is far more rocky. The discovery of the largest moon began the study of this system as a double planet, one that is doubtless the result of a collision somewhat similar to what occurred in Earth’s early history to form our Moon. We can only imagine how much more we’ll learn as New Horizons closes the distance to its target.

Image: New Horizons LOng Range Reconnaissance Imager (LORRI) composite image showing the detection of Pluto’s largest moon, Charon, cleanly separated from Pluto itself. The frame is an average of six different LORRI images, each taken with an exposure time of 0.1 second. No other Pluto system objects are seen in the image. Credit: NASA/Johns Hopkins University Applied Physics Laboratory/Southwest Research Institute.


Comments on this entry are closed.

  • Tom Baty July 11, 2013, 14:50

    “is doubtless the result of collision somewhat similar to what occurred in Earth’s early history to form our moon”. Those words stuck me as being very interesting. If there are two double planets in our solar system alone as a result of early collisions, does that give us a possible hint that double planets may well be common in other solar systems??? There are those that acclaim that a large moon is needed to stabilize the rotation and inclination of any inhabitable planet. (Rare Earth) Although I question that particular conclusion, even if it is true, then those who chose to believe that may just get their wish. That is if “double planets’ are indeed a common entity found in many other planetary systems. Just a thought.

  • RonSmith July 11, 2013, 17:00

    Be careful the IAU doesn’t get after you for calling Pluto a ‘planet’ throughout this article! :)

  • Paul Gilster July 11, 2013, 19:54

    True enough! Well, at least the first time I did refer to it as a ‘dwarf planet’… ;-)

  • Laurel Kornfeld July 11, 2013, 22:59

    Paul, I know RonSmith is joking, but many astronomers DO view dwarf planets as a subclass of planets, including New Horizons Principal Investigator Dr. Alan Stern, who first coined the term “dwarf planet.” I applaud your calling Pluto a planet and am convinced that the flyby in two years will reveal Pluto has the same complexity and structure as the larger planets; it’s just a smaller version. Even the IAU admits they have no power to make anyone “accept” their position and understand that the debate over Pluto’s planet status is very much ongoing.

  • David Cummings July 12, 2013, 7:52

    An ice-covered rock orbiting the sun by any other name…

  • Eric July 12, 2013, 8:33


    Could Kepler data be useful to detect double planets? I’m imagining a double system, with two large (Earth-sized?) bodies orbiting each other as they go around a red dwarf star. No tidal locking issues with the star then!

    Now that would be a really interesting scene.

  • Tom Baty July 12, 2013, 10:19

    @Eric: I totally agree with your premise, a double planet ( maybe not necessarily both being earth size) could very well mitigate the tidal locking problem of earth size planets in close orbits in the habitable zone of dwarf red stars. With the large number of M class stars that exist and if double planets likewise prove to be common; then the number of habitable planets around this class of stars could be greatly increases.

  • JoeP July 12, 2013, 12:29

    When looking at a side-by-side comparison between our Moon and Pluto, it really drives home how small Pluto is by comparison.

    Still, it is such a mysterious object, and I am looking forward to whatever we get from the flyby. Too bad we do not have an orbiter to witness the seasonal changes and atmosphere dynamics over time.

  • Rob Henry July 12, 2013, 19:54

    Laurel, I, in turn applaud your brave comments. To me the pivots around which that perception will turn include whether Ceres is found to be far more geologically interesting than Vesta, as well as the Pluto Charon encounter. To me a hint that the latter will be far from mundane, is the very large and rapid recent colour change on Pluto’s surface.

    PS. I hear that the IAU takes no prisoners so, till then, let’s just keep it between ourselves.

  • Joy July 12, 2013, 22:11

    A surprising fact concerning this system which is imagined to be so visually dark and dreary. At night on Charon, with a full Pluto overhead in the sky it would be fully as bright as a under a full moon at night on Earth! Solar flux 0.001 x area 200lunar x albedo 5lunar = full moonlight!

  • ljk July 14, 2013, 0:15

    ‘Star Trek’ on Pluto? It Could Really Happen, Scientists Say

    by Mike Wall, SPACE.com Senior Writer

    Date: 03 July 2013 Time: 07:00 AM ET

    While the naming gods have swatted away an attempt to christen one of Pluto’s newfound moons “Vulcan,” the “Star Trek” universe may still leave its mark on the dwarf planet soon enough.

    After NASA’s New Horizons spacecraft gets the first up-close views of Pluto in 2015, craters, mountains and other features spotted on the dwarf planet’s surface could bear the names of famous “Star Trek” characters, researchers said.

    “We might have craters called Sulu and Spock and Kirk and McCoy and so on,” Mark Showalter of the SETI (Search for Extraterrestrial Intelligence) Institute in Mountain View, Calif., said during a Google+ Hangout today (July 2).
