Terrain Clues to Ice in the Outer System

The human expansion into the Solar System will demand our being able to identify sources of water, a skill we’re honing as explorations continue. On Mars, for example, the study of so-called ‘pitted craters’ has been used as evidence that the low latitude regions of the planet, considered its driest, nonetheless have a layer of underlying ice. The Dawn spacecraft discovered similar pitted terrain on Vesta, as you can see in the image below.

Image: These enhanced-color views from NASA’s Dawn mission show an unusual “pitted terrain” on the floors of the craters named Marcia (left) and Cornelia (right) on the giant asteroid Vesta. The views show that the physical properties or composition of the material in which these pits form is different from crater to crater. Credit: NASA/JPL-Caltech/UCLA/MPS/DLR/IDA/JHUAPL.

Vesta’s Marcia crater contains the largest number of pits on the asteroid. The 70-kilometer feature is also one of the youngest craters found there. So what accounts for this kind of terrain? Perhaps the water that formed the pits came from Vesta itself. Another possibility: Low-speed collisions with carbon-rich meteorites could have deposited hydrated materials on the surface, to be released in the heat of subsequent high-speed collisions within the asteroid belt. An explosive degassing into space could explain such pothole-like depressions.

But Dawn wasn’t through when it left Vesta, and what it has found at Ceres is proving invaluable at understanding what appears to be a common marker of volatile-rich material. In new work from Hanna Sizemore (Planetary Science Institute) and colleagues, we learn that Ceres is home to the same kind of pitted terrain. As Sizemore notes:

“Now, we’ve found this same type of morphological feature on Ceres, and the evidence suggests that ice in the Cerean subsurface dominated the formation of pits there. Finding this type of feature on three different bodies suggests that similar pits might be found on other asteroids we will explore in the future, and that pitted materials may mark the best places to look for ice on those asteroids.”

Image: Haulani Crater, Ceres, showing abundant pitted materials on the crater floor. Similar pitted materials have previously been identified on Mars and Vesta, and are associated with rapid volatile release following impact. Their discovery on Ceres indicates pitted materials may be a common morphological indicator of volatile-rich materials in the asteroid belt. Haulani Crater is 34 km in diameter. Color indicates topography. Credit: NASA/MPS/PSI/Thomas Platz.

Sizemore’s team studied the formation of pitted craters on Ceres through numerical models that explored the role of water ice and other volatiles. The morphological similarities between the Ceres features and what has been found on Mars and Vesta are striking. With water ice evidently significant in pit development on two asteroids and a planet, similar terrains will be of clear interest for future missions in terms of in situ resource utilization.

Image: Pitted terrain on Mars as seen by HiRISE aboard the Mars Reconnaissance Orbiter. Credit: NASA/JPL/University of Arizona.

The paper is Sizemore et al., “Pitted Terrains on (1) Ceres and Implications for Shallow Subsurface Volatile Distribution,” accepted at Geophysical Research Letters (preprint).


Comments on this entry are closed.

  • Alex Tolley July 11, 2017, 15:35

    If this analysis is correct, it should be fairly easy to map such features on celestial bodies. Relatively low-cost instruments could do the task using ML to identify the features.

    If the propulsion of this craft could use water, it could extract and purify the water from asteroids making the extensive mapping of many asteroids a highly automated process.

    I could imagine a small fleet of these craft slowly mapping the asteroid belt with locations of water deposits for ship refueling and life support. Automated water extraction plants could follow, setting up part of the infrastructure for the inner solar system economy.

  • Harry R Ray July 11, 2017, 17:39

    Ice-7 has been FINALLY CREATED in the laboratory!!!

    • Haxo Angmark July 11, 2017, 23:49

      2 steps away from…the Big Freeze.

      • Harry R Ray July 12, 2017, 9:32

        I assume you are referring to Kurt Vonnegut’s “Cat’s Cradle” and Ice-9.

        • Haxo Angmark July 12, 2017, 15:03

          you got it. Another “filter”. How many extra-solar civilizations have foolishly “iced” themselves?

          • Brett Bellmore July 13, 2017, 8:32

            Almost certainly none, because if “ice nine” were actually stable at anything like STP, in several billion years the planet would have somehow managed to get turned into an iceball.

            • Haxo Angmark July 14, 2017, 1:14

              I will attempt no more jocularities.

              • Michael July 15, 2017, 14:23

                I don’t believe this site is about strict conformity.

                Please continue with the jocularities, after all isn’t all sci-fi based on subjects we later laugh at !

                • Harry R Ray July 17, 2017, 9:17

                  lol UBER ALLES!!!!!!!!!
